JT125T-30
Product Details
| ENGINE | |
| Engine Type | C125 engine, single cylinder, air cooled, 4 stroke |
| Bore and Stroke | 52.4 x 55.5 mm |
| Displacement | 119.7 ml |
| Compression Ratio | 9.0:1 |
| Maximun Power | 5.8 kw / 7500r / min |
| Maximun Torque | 8.5 N.m/5000r/min |
| Transmission | 4 gear shifting |
| Ignition | CDI |
| Starting | Electric & kick starting |
| Clutch | Automatic clutch |
| CHASSIS / SUSPENSION / BRAKES | |
| Front Suspension | Hydraulic damp |
| Rear Suspension | Mid-ship single spring shock absorber |
| Front Brake | Single disc |
| Rear Brake | Single disc |
| Front Tire | 120/70-12 |
| Rear Tire | 130/70-12 |
| DIMENSIONS | |
| Height | 1070 mm |
| Width | 670 mm |
| Length | 1790 mm |
| Wheel Base | 1190 mm |
| WARRANTY | |
| 1 year or 6000km factory warranty |
