JT125T-45

Product Details
ENGINE
Engine Type GY6 engine, single cylinder, forced air cooled, 4 stroke
Bore and Stroke 52.4 x 57.8 mm
Displacement 124.6 ml
Compression Ratio 9.2:1
Maximun Power 5.2 kw / 7500r / min
Maximun Torque 7.5 N.m / 6000r / min
Transmission V-belt automatic
Ignition CDI
Starting Electric & kick starting
Clutch Automatic clutch
CHASSIS / SUSPENSION / BRAKES
Front Suspension Hydraulic damp
Rear Suspension Double spring shock absorber
Front Brake Single disc
Rear Brake Drum brake
Front Tire 3.50-10
Rear Tire 3.50-10
DIMENSIONS
Height 1100 mm
Width 640 mm
Length 19000 mm
Wheel Base 1280 mm
WARRANTY
1 year or 6000km factory warranty
