JT300-69
Product Details
| SPECIFICATIONS: | JT300-69 |
| ENGINE | CBB300 |
| Engine Type | Single cylinder, water cooled, 4 stroke, balance shaft |
| Bore and Stroke | 74 x 65 mm |
| Displacement | 279.5 ml |
| Compression Ratio | 10.2:1~11.1:1 |
| Maximun Power | 18.5 kw / 8500r / min |
| Maximun Torque | 23.0 N.m / 7000r / min |
| Transmission | 6 gear shifting |
| Ignition | CDI |
| Starting | Electric & kick starting |
| Clutch | Hand clutch |
| CHASSIS / SUSPENSION / BRAKES | |
| Front Suspension | Inverted Telescopic fork, Hydraulic damp |
| Rear Suspension | Mid-ship single spring shock absorber |
| Front Brake | Double disk |
| Rear Brake | Single disc |
| Front Tire | 120/70-17 |
| Rear Tire | 150/70-17 |
| DIMENSIONS | |
| Height | 1150 mm |
| Width | 760 mm |
| Length | 2030 mm |
| Wheel Base | 1410 mm |
| WARRANTY | |
| 1 year or 6000km factory warranty |
